POWERWALKER Basic VI 650VA Line-Interactive UPS

The PowerWalker Basic VI SB series is designed to answer the essential market needs. This Line-Interactive UPS will protect your load from power failures and voltage disturbances, while remaining affordable and compact. It is equipped with a USB port with HID support allowing an easy and direct communication with any O/S.

Features

• Human Interface Device (HID) Supported.
• Compact and Lightweight.
• Equipped with Boost and Buck (AVR).
• Cold (DC) Start Function.
• Silent Operation (Zzz Zzz…).

Specifications
General features

• Type: Line-Interactive (VI)
• Phases (IN-OUT): 1-1
• Form Factor: Tower
• Power Capacity: 650VA / 360W
• Output Power Factor: 0.55

Input

• Input Voltage Range: 162-290 VAC
• Frequency Range: 50Hz or 60Hz (self-adaptive)

Output

• Waveform: Simulated Sine Wave
• Nominal Output Voltage: 230 VAC
• Frequency (Battery Mode): ±0.05Hz

Input & Output Connectors

• Input Connector: UK
• Output Type: Type G
• Type G (BS 1363): 2

Technical details

• LINE Mode Efficiency [%] (Full Load): 96.8
• Transfer Time (AC / Line Mode to Battery Mode): 4ms
• Additional Features: HID – Human Interface Device, AVR – Automatic Voltage Regulator, Cold-Start Function
• IEC 62040-3 classification: VI-SY-333

Batteries and autonomy

• Batteries: 1x 12.0V/5.0Ah
• DC Voltage: 1x 12.0V
• Recharge Time: 8h to 90%
• Full Load Backup Time [min]: 0.0
• Half Load Backup Time [min]: 4.5
• Charger: 0.7A
